2/3" 3 Megapixel Series

High-performance Machine Vision lenses that support 3-megapixel 2/3"-format sensors. The new lenses maintain their sharpness even when wide open under low light conditions or during the change of shooting distance while maintaining edge-to-edge sharpness from the image center to all corners for higher image recognition accuracy.

HF8XA-1

Specification
Mount C
Focal length 8 mm
Focus Manual
Iris Range F1.6 - F16
Iris Manual
Applicable for Pixel Pitch 4.4μm
Distortion -2.0%
Object Dimensions at M.O.D. 0.1 mm
Angular Field of View 58°46′ × 44°56′
Focusing Range (From Front of the Lens) ∞ - 0.1 m
Filter Thread M25.5 × 0.5 mm
Mass 79 g

HF12XA-1

Specification
Mount C
Focal length 12 mm
Focus Manual
Iris Range F1.6 - F16
Iris Manual
Applicable for Pixel Pitch 4.4μm
Distortion -0.7%
Object Dimensions at M.O.D. 0.1 mm
Angular Field of View 40°05′ × 30°23′
Focusing Range (From Front of the Lens) ∞ - 0.1 m
Filter Thread M25.5 × 0.5 mm
Mass 79 g

HF16XA-1

Specification
Mount C
Focal length 16 mm
Focus Manual
Iris Range F1.6 - F16
Iris Manual
Applicable for Pixel Pitch 4.4μm
Distortion -0.6%
Object Dimensions at M.O.D. 0.1 mm
Angular Field of View 30°47′ × 23°13′
Focusing Range (From Front of the Lens) ∞ - 0.1 m
Filter Thread M25.5 × 0.5 mm
Mass 71 g

HF25XA-1

Specification
Mount C
Focal length 25 mm
Focus Manual
Iris Range F1.6 - F16
Iris Manual
Applicable for Pixel Pitch 4.4μm
Distortion -0.1%
Object Dimensions at M.O.D. 0.1 mm
Angular Field of View 19°46′ × 14°53′
Focusing Range (From Front of the Lens) ∞ - 0.1 m
Filter Thread M25.5 × 0.5 mm
Mass 72 g

HF35XA-1

Specification
Mount C
Focal length 35 mm
Focus Manual
Iris Range F1.9 - F16
Iris Manual
Applicable for Pixel Pitch 4.4μm
Distortion 0.1%
Object Dimensions at M.O.D. 0.2 mm
Angular Field of View 14°13′ × 10°41′
Focusing Range (From Front of the Lens) ∞ - 0.2 m
Filter Thread M25.5 × 0.5 mm
Mass 60 g

1" 1.5 Megapixel Series

High-resolution design, providing support for up to 1.5 megapixel camera resolution. Rear focusing system provides improved performance in macro photography. Wide-aperture (F1.4) design achieves clear images under low light intensity. Low-distortion design achieving accurate image input. Robust enclosure resistant to vibrations and shocks. Equipped with locking knobs for the iris and the focus

CF12.5HA-1

Specification
Mount C
Focal length 12.5 mm
Focus Manual
Iris Range F1.4 - F22
Iris Manual
Back Focal Distance (In Air) 16.07 mm
Exit Pupil Position (From Image Plane) -101 mm
Object Dimensions at M.O.D. 120 × 90 mm
Angular Field of View 54°13′ × 42°01′
Focusing Range (From Front of the Lens) ∞ - 0.1 m
Filter Thread M49 × 0.75 mm
Mass 290 g

CF16HA-1

Specification
Mount C
Focal length 16 mm
Focus Manual
Iris Range F1.4 - F22
Iris Manual
Back Focal Distance (In Air) 17.99 mm
Exit Pupil Position (From Image Plane) -172 mm
Object Dimensions at M.O.D. 100 × 75 mm
Angular Field of View 43°36′ × 33°24′
Focusing Range (From Front of the Lens) ∞ - 0.1 m
Filter Thread M49 × 0.75 mm
Mass 280 g

CF25HA-1

Specification
Mount C
Focal length 25 mm
Focus Manual
Iris Range F1.4 - F22
Iris Manual
Back Focal Distance (In Air) 22.32 mm
Exit Pupil Position (From Image Plane) -140 mm
Object Dimensions at M.O.D. 65 × 48 mm
Angular Field of View 28°43′ × 21°44′
Focusing Range (From Front of the Lens) ∞ - 0.1 m
Filter Thread M49 × 0.75 mm
Mass 310 g

CF34HA-1

Specification
Mount C
Focal length 35 mm
Focus Manual
Iris Range F1.4 - F22
Iris Manual
Back Focal Distance (In Air) 14.99 mm
Exit Pupil Position (From Image Plane) -37 mm
Object Dimensions at M.O.D. 73 × 55 mm
Angular Field of View 20°43′ × 15°37′
Focusing Range (From Front of the Lens) ∞ - 0.2 m
Filter Thread M49 × 0.75 mm
Mass 180 g

CF50HA-1

Specification
Mount C
Focal length 50 mm
Focus Manual
Iris Range F1.8 - F22
Iris Manual
Back Focal Distance (In Air) 17.81 mm
Exit Pupil Position (From Image Plane) -49 mm
Object Dimensions at M.O.D. 101 × 76 mm
Angular Field of View 14°35′ × 10°58′
Focusing Range (From Front of the Lens) ∞ - 0.4 m *
Filter Thread M49 × 0.75 mm
Mass 235 g

CF75HA-1

Specification
Mount C
Focal length 75 mm
Focus Manual
Iris Range F1.8 - F22
Iris Manual
Back Focal Distance (In Air) 24.43 mm
Exit Pupil Position (From Image Plane) -52 mm
Object Dimensions at M.O.D. 147 × 111 mm
Angular Field of View 9°45′ × 7°19′
Focusing Range (From Front of the Lens) ∞ - 0.9 m
Filter Thread M49 × 0.75 mm
Mass 295 g

2/3" 1.5 Megapixel Series

Design achieving the high-resolution, supporting up to 1.5 megapixel cameras. Designed for low distortion, enabling faithful image input. Compact, lightweight and robust design, supporting various systems. Focus & iris lock tab provided, supporting environments such as vibration.

HF9HA-1B

Specification
Mount C
Focal length 9 mm
Focus Manual
Iris Range F1.4 - F16
Iris Manual
Back Focal Distance (In Air) 13.48 mm
Exit Pupil Position (From Image Plane) -27.9 mm
Object Dimensions at M.O.D. 108 × 81 mm
Angular Field of View 52°06′ × 40°16′
Focusing Range (From Front of the Lens) ∞ - 0.1 m
Filter Thread M27 × 0.5 mm
Mass 55 g

HF12.5HA-1B

Specification
Mount C
Focal length 12.5 mm
Focus Manual
Iris Range F1.4 - F16
Iris Manual
Back Focal Distance (In Air) 15.09 mm
Exit Pupil Position (From Image Plane) -31.3 mm
Object Dimensions at M.O.D. 78 × 58 mm
Angular Field of View 38°47′ × 29°35′
Focusing Range (From Front of the Lens) ∞ - 0.1 m
Filter Thread M25.5 × 0.5 mm
Mass 45 g

HF16HA-1B

Specification
Mount C
Focal length 16 mm
Focus Manual
Iris Range F1.4 - F16
Iris Manual
Back Focal Distance (In Air) 15.15 mm
Exit Pupil Position (From Image Plane) -30.9 mm
Object Dimensions at M.O.D. 63 × 47 mm
Angular Field of View 30°45′ × 23°18′
Focusing Range (From Front of the Lens) ∞ - 0.1 m
Filter Thread M25.5 × 0.5 mm
Mass 45 g

HF25HA-1B

Specification
Mount C
Focal length 25 mm
Focus Manual
Iris Range F1.4 - F22
Iris Manual
Back Focal Distance (In Air) 14.58 mm
Exit Pupil Position (From Image Plane) -32.4 mm
Object Dimensions at M.O.D. 53 × 40 mm
Angular Field of View 19°58′ × 15°02′
Focusing Range (From Front of the Lens) ∞ - 0.15 m
Filter Thread M25.5 × 0.5 mm
Mass 45 g

HF35HA-1B

Specification
Mount C
Focal length 35 mm
Focus Manual
Iris Range F1.6 - F22
Iris Manual
Back Focal Distance (In Air) 15.03 mm
Exit Pupil Position (From Image Plane) -26.6 mm
Object Dimensions at M.O.D. 59 × 44 mm
Angular Field of View 14°20′ × 10°46′
Focusing Range (From Front of the Lens) ∞ - 0.25 m
Filter Thread M25.5 × 0.5 mm
Mass 45 g

HF50HA-1B

Specification
Mount C
Focal length 50 mm
Focus Manual
Iris Range F2.3 - F22
Iris Manual
Back Focal Distance (In Air) 15.26 mm
Exit Pupil Position (From Image Plane) -25.1 mm
Object Dimensions at M.O.D. 77 × 57 mm
Angular Field of View 10°03′ × 7°33′
Focusing Range (From Front of the Lens) ∞ - 0.5 m
Filter Thread M25.5 × 0.5 mm
Mass 45 g

HF75HA-1B

Specification
Mount C
Focal length 75 mm
Focus Manual
Iris Range F2.8 - F22
Iris Manual
Back Focal Distance (In Air) 15.74 mm
Exit Pupil Position (From Image Plane) -26.6 mm
Object Dimensions at M.O.D. 114 × 85 mm
Angular Field of View 6°43′ × 5°02′
Focusing Range (From Front of the Lens) ∞ - 1.1 m
Filter Thread M30.5 × 0.5 mm
Mass 55 g

1/3" High Resolution for 3CCD

Special design for optimizing the image quality of 3CCD cameras. Low-distortion design achieving accurate image input. Compact, lightweight and robust design, supporting various systems. Faithful color reproduction for 3CCD cameras, best suited for advanced monitoring applications.

TF2.8DA-8

Specification
Mount C
Focal length 2.8 mm
Focus Manual
Iris Range F2.2 - F16 * Close
Iris Manual
Back Focal Distance (In Air) 14.49 mm
Exit Pupil Position (From Image Plane) 98 mm
Object Dimensions at M.O.D. 218 × 153 mm
Angular Field of View 89°08′ × 69°20′
Focusing Range (From Front of the Lens) ∞ - 0.1 m
Filter Thread -
Mass 75 g

TF4DA-8

Specification
Mount C
Focal length 4 mm
Focus Manual
Iris Range F2.2 - F16 * Close
Iris Manual
Back Focal Distance (In Air) 14.61 mm
Exit Pupil Position (From Image Plane) 88 mm
Object Dimensions at M.O.D. 131 × 98 mm
Angular Field of View 61°56′ × 48°27′
Focusing Range (From Front of the Lens) ∞ - 0.1 m
Filter Thread M27 × 0.5 mm
Mass 70 g

TF8DA-8B

Specification
Mount C
Focal length 8 mm
Focus Manual
Iris Range F2.2 - F16 * Close
Iris Manual
Back Focal Distance (In Air) 14.83 mm
Exit Pupil Position (From Image Plane) -176 mm
Object Dimensions at M.O.D. 66 × 50 mm
Angular Field of View 33°24′ × 25°22′
Focusing Range (From Front of the Lens) ∞ - 0.1 m
Filter Thread M25.5 × 0.5 mm
Mass 60 g

TF15DA-8

Specification
Mount C
Focal length 15 mm
Focus Manual
Iris Range F2.2 - F16 * Close
Iris Manual
Back Focal Distance (In Air) 16.32 mm
Exit Pupil Position (From Image Plane) -89 mm
Object Dimensions at M.O.D. 36 × 27 mm
Angular Field of View 18°11′ × 13°41′
Focusing Range (From Front of the Lens) ∞ - 0.1 m
Filter Thread M25.5 × 0.5 mm
Mass 60 g

TF25DA-8B

Specification
Mount C
Focal length 25 mm
Focus Manual
Iris Range F2.2 - F16 * Close
Iris Manual
Back Focal Distance (In Air) 15.12 mm
Exit Pupil Position (From Image Plane) -120 mm
Object Dimensions at M.O.D. 42 × 32 mm
Angular Field of View 10°58′ × 8°14′
Focusing Range (From Front of the Lens) ∞ - 0.2 m
Filter Thread M25.5 × 0.5 mm
Mass 60 g

2/3" 5 Megapixel Series

High-resolution design, providing support for up to 5 megapixel camera resolution. Rear focusing system provides improved performance in macro photography. Wide-aperture (F1.4) design achieves clear images under low light intensity. Enhanced image recognition accuracy achieved by reduction of distortion and improvement of illumination uniformity. Robust enclosure resistant to vibrations and shocks. Equipped with locking knobs for the iris and the focus.

HF12.5SA-1

Specification
Mount C
Focal length 12.5 mm
Focus Manual
Iris Range F1.4 - F22
Iris Manual
Back Focal Distance (In Air) 16.07 mm
Exit Pupil Position (From Image Plane) -101 mm
Object Dimensions at M.O.D. 83 × 62 mm
Angular Field of View 38°47′ × 29°35′
Focusing Range (From Front of the Lens) ∞ - 0.1 m
Filter Thread M49 × 0.75 mm
Mass 295 g

HF16SA-1

Specification
Mount C
Focal length 16 mm
Focus Manual
Iris Range F1.4 - F22
Iris Manual
Back Focal Distance (In Air) 17.99 mm
Exit Pupil Position (From Image Plane) -172 mm
Object Dimensions at M.O.D. 69 × 51 mm
Angular Field of View 30°45′ × 23°18′
Focusing Range (From Front of the Lens) ∞ - 0.1 m
Filter Thread M49 × 0.75 mm
Mass 285 g

HF25SA-1

Specification
Mount C
Focal length 25 mm
Focus Manual
Iris Range F1.4 - F22
Iris Manual
Back Focal Distance (In Air) 22.32 mm
Exit Pupil Position (From Image Plane) -140 mm
Object Dimensions at M.O.D. 44 × 33 mm
Angular Field of View 19°58′ × 15°02′
Focusing Range (From Front of the Lens) ∞ - 0.1 m
Filter Thread M49 × 0.75 mm
Mass 315 g

HF35SA-1

Specification
Mount C
Focal length 35 mm
Focus Manual
Iris Range F1.4 - F22
Iris Manual
Back Focal Distance (In Air) 14.99 mm
Exit Pupil Position (From Image Plane) -37 mm
Object Dimensions at M.O.D. 50 × 38 mm
Angular Field of View 14°20′ × 10°46′
Focusing Range (From Front of the Lens) ∞ - 0.2 m
Filter Thread M49 × 0.75 mm
Mass 185 g

HF50SA-1

Specification
Mount C
Focal length 50 mm
Focus Manual
Iris Range F1.8 - F22
Iris Manual
Back Focal Distance (In Air) 17.81 mm
Exit Pupil Position (From Image Plane) -49 mm
Object Dimensions at M.O.D. 70 × 52 mm
Angular Field of View 10°03′ × 7°33′
Focusing Range (From Front of the Lens) ∞ - 0.4 m *1
Filter Thread M49 × 0.75 mm
Mass 240 g

HF75SA-1

Specification
Mount C
Focal length 75 mm
Focus Manual
Iris Range F1.4 - F22
Iris Manual
Back Focal Distance (In Air) 16.07 mm
Exit Pupil Position (From Image Plane) -101 mm
Object Dimensions at M.O.D. 83 × 62 mm
Angular Field of View 38°47′ × 29°35′
Focusing Range (From Front of the Lens) ∞ - 0.1 m
Filter Thread M49 × 0.75 mm
Mass 295 g

1/2" 1.5 Megapixel Series

Design achieving the high resolution, supporting up to 1.5 megapixel cameras. Designed for low distortion, enabling faithful image input. Compact, lightweight and robust design, supporting various systems. Focus & iris lock tab provided, supporting environments such as vibration.

DF6HA-1B

Specification
Mount C
Focal length 6 mm
Focus Manual
Iris Range F1.2 - F16
Iris Manual
Back Focal Distance (In Air) 11.44 mm
Exit Pupil Position (From Image Plane) -46 mm
Object Dimensions at M.O.D. 122 × 92 mm
Angular Field of View 56°09′ × 43°36′
Focusing Range (From Front of the Lens) ∞ - 0.1 m
Filter Thread M27 × 0.5 mm
Mass 55 g
