Description
Specifications
| Category | Attribute | Value |
| Display* |
Backlight MTBF(hrs)
|
50,000 hrs |
| Contrast Ratio |
500:1
|
|
| Display Size | 16.5″ | |
| Display Type |
WXGA TFT LED LCD
|
|
| Luminance (cd/m2) | 250 | |
| Max. Colors | 16.7 M | |
| Max. Resolution |
1366 x 768
|
|
| Viewing Angle (H/V°) |
178/178
|
| Category | Attribute | Value |
| General | Certifications* | BSMI, CCC, CE, FCC Class A, UL, CB |
| Dimensions (W x H x D)* |
419.7 x 269 x 56.2 mm (16.52″ x 10.59″ x 2.21″)
|
|
| Enclosure* | Front panel: Die-casting aluminium,Rear cover: Die-casting aluminium | |
| Mounting* | Panel, wall, desktop, VESA arm | |
| Power Input* |
External 60 W power adapter, with AC 100 V ~ 240 V input and DC +12 V @ 5 A output (included)
|
|
| Video Port* |
VGA / HDMI
|
|
| Weight (Net)* |
4 kg
|
| Category | Attribute | Value |
| Environment | Humidity (Storage)* | 10 ~ 95% non-condensing |
| Operating Temperature | 0 ~ 50° C (32 ~ 122° F) | |
| Storage Temperature | -20 ~ 60°C (-4 ~ 140°F) | |
| Vibration* | 5 ~ 500 Hz, 1 Grms (Operating, Random) | |
| Waterproof* |
Front panel IP65 compliant
|
| Category |
Multi Touch*
|
4 points, USB interface in Win 7/8/10, Linux
|
| Touchscreen | Hardness* | 7H |
| OS Support* |
Windows® 7, 8, 10, XPe, CE and Linux
|
|
| Touch Type | 5-wire, analog resistive | |
| USB |
