15.6″ WXGA Ind. Monitor, with PCAP touch (HDMI)

  • 15.6″ WXGA TFT LED LCD with true-flat touchscreen
  • 16:9 wide screen aspect ratio, increases viewing area by 40%
  • Supports 10-point multi-touch control via USB interface in Windows 7/8/10 OS
  • Slim design enables easy installation
  • Supports various mount options: panel, wall, desktop, and VESA arm
  • Touchscreen with reliable glass surface and P-CAP touch control
  • Robust system with Die-casting aluminum chassis and IP66-rated aluminum alloy front bezel
  • Lockable I/O connectors

Description

Specifications

Category Attribute Value
Display*
Backlight MTBF(hrs)
50,000 hrs
Contrast Ratio
500:1
Display Size 16.5″
Display Type
WXGA TFT LED LCD
Luminance (cd/m2) 250
Max. Colors 16.7 M
Max. Resolution
1366 x 768
Viewing Angle (H/V°)
178/178
Category Attribute Value
General Certifications* BSMI, CCC, CE, FCC Class A, UL, CB
Dimensions (W x H x D)*
419.7 x 269 x 56.2 mm (16.52″ x 10.59″ x 2.21″)
Enclosure* Front panel: Die-casting aluminium,Rear cover: Die-casting aluminium
Mounting* Panel, wall, desktop, VESA arm
Power Input*
External 60 W power adapter, with AC 100 V ~ 240 V input and DC +12 V @ 5 A output (included)
Video Port*
VGA / HDMI
Weight (Net)*
4 kg
Category Attribute Value
Environment Humidity (Storage)* 10 ~ 95% non-condensing
Operating Temperature 0 ~ 50° C (32 ~ 122° F)
Storage Temperature -20 ~ 60°C (-4 ~ 140°F)
Vibration* 5 ~ 500 Hz, 1 Grms (Operating, Random)
Waterproof*
Front panel IP65 compliant
Category
Multi Touch*
4 points, USB interface in Win 7/8/10, Linux
Touchscreen Hardness* 7H
OS Support*
Windows® 7, 8, 10, XPe, CE and Linux
Touch Type 5-wire, analog resistive
USB
