W22IB7T-PMA3

W22IB7T-PMA3

Features
  • 21.5″ TFT SXGA LCD
  • Intel® Celeron Bay Trial-M N2930 1.83GHz Processor
  • DDR3L -1066/1333 MHz SO-DIMM x 2 Slot (MAX to 8GB)
  • Integrated VGA, 24 bit Dual-channel LVDS, DVI
  • Integrated Dual Broadcom BCM57780 GbE Controller
  • 1 x SATA II, 3 x COM, 3 x USB 2.0,1 x USB 3.0,19 x GPIO, 2x Mini PCIe slot
Contact Us



Description

LCD Panel Specification
Size 21.5″(16:9)
Active Display Area 476.64 (H) x 268.11 (V)
Pixel Pitch 248.25(per one triad)(H) x 248.25(V)
Resolution 1920×1080
Contrast Ratio 1000:1 (typ.)
Display Color 16.7M (8bits/color)
Brightness 250 (typ.)
Viewing Angle -89~89 (H); -89~89 (V)
Recommend Resolution 1920×1080 @60Hz
Power Input AC 110~240 V
Power Consumption 60W (typ.)(Max.backlight & high CPU load)
Power Management VESA DPMS Compliant
Plug Play VESA DDC 1/2B
Touch Sensor Type Resistive
System Specification
FormFactor Mini-ITX
Processor Intel® Celeron Bay Trial-M N2930 1.83GHz Processors
Chipset Intel Atom SoC Integrated
Memory DDR3L -1066/1333 MHz SO-DIMM x 2 Slot (MAX to 8GB)
BIOS AMI 16Mbit
LCD Support Single Channel 24-bit LVDS
Ethernet Dual Broadcom BCM57780 GbE Controller
Audio Realtek ALC888 HD Audio Codec
SATA 1 x SATAII
I/O Chipset Fintek F81865
Serial 2 x RS232, 1 x RS232/422/485
USB 1 x USB 3.0, 3 x USB 2.0
KB / Mouse Connector 2 x PS/2
DVD Optional No
Storage 2.5 inch HDD
FDD Optional No
OS Windows 10 IoT Enterprise / Windows 8 Embedded / Windows 7 Embedded
Power Adapter DC IN 12V
Temperature Operating : 0°C to 50°C
Humidity Operating : 30% to 90% (non-condensing)
Shock Operating:15G, 11ms duration
Vibration Operating: 5 Hz ~ 500 Hz/ 1 Grms/ 3 Axis Packing:: 5 Hz ~ 500 Hz/ 2.16 Grms/ 3 Axis
Net Weight (kg) (without touch) 0.0
Gross Weight(kg) 0.0
Security Support Trusted Platform Module (TPM 1.2)
  • *The weight information is for reference purpose.The actual weight will vary according to then options you choose,for example,the touch/glass option.
  • Note: All Specifications are subject to change without prior notice!
    *If you use SBC on-board RS485, you need to set appropriate state of RTS line before sending/receiving data in your software program.We offer additional board that can perform auto-direction hardware function.
